SD-WAN routing confuses people because there are really two routing problems happening at once, and they are easy to mix up. There is the routing inside the SD-WAN fabric - how sites learn each other's prefixes across the overlay - and there is the routing of the physical transports underneath. Keep those two layers separate and SD-WAN routing becomes straightforward. This post walks through both, using the Cisco Catalyst SD-WAN (formerly Viptela) model.
For the cluster overview, see the SD-WAN complete guide.
Two layers: underlay and overlay
Every SD-WAN design has two routing layers stacked on top of each other.
The important shift in mindset: the underlay does almost no routing work. It does not need to know a single enterprise prefix. Its only job is to get an SD-WAN router's transport interface reachable to the others - usually a default route from the ISP, or a simple route over MPLS. All the real routing intelligence lives in the overlay.
TLOCs: how the fabric describes a connection
Before the overlay routing makes sense, one term: a TLOC (Transport Locator) is how SD-WAN identifies a router's attachment to a transport. A TLOC is essentially the tuple of "this router, on this transport (color), with this encapsulation." A router with an MPLS link and a broadband link has two TLOCs.
TLOCs are the next-hops of the SD-WAN world. When the fabric advertises a prefix, it advertises it as reachable via a TLOC. Steering traffic onto MPLS instead of broadband is, underneath, choosing one TLOC over another.
OMP: the control plane of the fabric
The overlay's routing protocol is OMP - the Overlay Management Protocol. If you know BGP, OMP will feel familiar: it is a single protocol that distributes everything the fabric needs, and the edge routers do not peer with each other directly. Instead, every edge router peers with a central controller (the vSmart controller), and the controller reflects routing information to everyone - the same hub-and-spoke control model as a BGP route reflector.
OMP carries three things:
- OMP routes - the enterprise prefixes at each site, advertised with their TLOC next-hop.
- TLOC routes - the transport attachment points themselves, with their public/private addresses.
- Service routes - advertisements for services (firewall, IPS) that traffic can be steered through.
Because OMP runs to a central controller, policy is applied centrally. The controller can shape what each site learns and which paths it prefers, without anyone touching an edge router.
Service-side routing: getting LAN prefixes into OMP
OMP handles the fabric. It does not, by itself, know about the LAN behind each site. That is the service side - the VRF/VPN facing the local network.
On the service side, an SD-WAN edge router runs ordinary routing. It learns local subnets through connected interfaces, static routes, OSPF, or BGP with the site's LAN switches. Those learned prefixes are then redistributed into OMP so the rest of the fabric can reach them. The reverse happens too: OMP routes from other sites are redistributed back into the local OSPF or BGP so LAN devices have a path out.
So the full chain for a packet's route is: LAN routing protocol redistributes into OMP, OMP carries it across the fabric to every other site, and OMP redistributes back into each remote site's LAN routing protocol. The edge router is the translation point at both ends.
Path selection: the part that makes SD-WAN "SD"
This is where SD-WAN routing stops resembling traditional routing. Traditional routing picks one best path by metric and sends everything down it. SD-WAN picks paths per application, based on measured performance.
The edge routers continuously probe each tunnel with BFD, measuring loss, latency, and jitter. A centralized application-aware routing policy then defines SLA classes - for example, "voice needs under 150 ms latency, under 2 percent loss." Traffic for an application is sent down whichever transport currently meets its SLA. If the preferred transport degrades, that application is moved to a transport that still meets the SLA, while other traffic may stay where it is.
The result: a brownout on the MPLS circuit can move voice to broadband within a couple of seconds, automatically, with no routing reconvergence in the traditional sense. The OMP routes did not change - the policy chose a different TLOC.
The configuration shape
Most SD-WAN routing is expressed as centralized policy on the controller rather than per-router CLI, but the per-site service-side routing is recognizable IOS XE:
! Service-side VRF on a Catalyst SD-WAN edge router
vrf definition 10
rd 1:10
address-family ipv4
!
router ospf 10 vrf 10
redistribute omp subnets
!
! OMP redistributes the service-side routes back into the fabric
router omp
address-family ipv4 vrf 10
advertise ospfCommon gotchas
Key takeaways
SD-WAN routing is two layers. The underlay (MPLS, broadband, LTE) only has to provide IP reachability between edge routers and carries no enterprise prefixes. The overlay carries the real routing, using OMP - a BGP-like protocol where every edge router peers with a central controller that reflects routes, advertising prefixes via TLOC next-hops. Each site's LAN prefixes are learned by ordinary OSPF, BGP, or static routing on the service side and redistributed into OMP, then redistributed back into the LAN at remote sites. The defining feature is application-aware path selection: BFD probes measure each tunnel, and centralized SLA policy steers each application onto whichever transport currently meets its requirements.
