Lab ipc-13 - VRRP vs HSRP Comparison

Lab ipc-13 - VRRP vs HSRP Comparison - PingLabz Labs article title card

VRRP (Virtual Router Redundancy Protocol, RFC 5798) is the open-standard equivalent of HSRP. Same idea: two or more routers share a virtual IP; one is the Master, others are Backup. The differences from HSRP are minor and mostly historical. This lab configures VRRP alongside HSRP on the same routers to show how similar the two protocols are - and where they differ.

What you will learn

  • VRRP architecture and terminology (Master vs Active, Backup vs Standby)
  • The VRRP virtual MAC format (0000.5e00.01XX)
  • VRRP version 2 (the standard) vs version 3 (newer, supports IPv6)
  • How to read show vrrp and show vrrp brief
  • The HSRP-vs-VRRP comparison table

What this lab does NOT cover

  • VRRPv3 + IPv6
  • GLBP - the next lab, ipc-14

Topology

Download the CCNA Base Topology .yaml

The PingLabz CCNA Base Topology - 3 iol-xe routers + 1 alpine + 1 ioll2-xe switch.

Download CCNA Base Topology
