The CCIE EI Super Lab Library

The CCIE EI Super Lab Library - four full-scale integration labs plus a ticket gauntlet

Reading the 58 free CCIE articles closes the knowledge gap. The Super Labs close the gap the CCIE lab actually tests: integration - making every technology work together at once, and finding the fault fast when it does not. These are four full-scale, multi-technology labs plus a ticket gauntlet, built on the same real component labs behind every article in the CCIE study hub.

Prerequisites

The Super Labs assume the foundations are in place. Work them in this order:

1
The CCNA lab library - the 60-lab fundamentals build. Get here first if your basics are rusty.
2
The CCNP clusters - BGP, OSPF, EIGRP, MPLS, VLANs, and the rest, linked from each pillar page.
3
The CCIE study hub - all 58 expert articles, blueprint-mapped. Read the domain, then lab it.
4
These Super Labs - where it all converges.

The four Super Labs

1
The Enterprise Core Pro
Switched campus (MST + HSRP + L2 security) + OSPF core + dual-homed BGP edge + dual-hub DMVPN WAN + services, built and verified end to end. The lab that looks most like a real enterprise.
2
The Service Provider Handoff Pro
MPLS L3VPN with 6VPE over an IPv4 core, BGP PE-CE with as-override and SoO, overlapping customer space, and QoS on the PE-CE links. The provider that connects the enterprises.
3
The Ticket Gauntlet Pro
One converged topology, twelve pre-planted faults across every domain, a timer, and a gated answer key with the diagnostic trail for each. The best preparation for the troubleshooting section there is.
4
Overlay and Automation Pro
Multicast (PIM SM), the SD-Access component protocols (LISP, VXLAN) standalone, and an automation harness that renders and pushes config from a Linux host - the overlay-plus-automation frontier.

Hardware and CML requirements

The Super Labs run on the same lightweight virtual platforms as the component labs - iol-xe for routers, ioll2-xe for switches, net-tools for hosts - so a modest Cisco Modeling Labs server carries them comfortably. The largest (Super Lab 1) is 8 to 10 nodes; watch the server RAM with show statistics before booting the full topology and trim a spoke if it is tight. A real Linux VM bridged into the fabric (as the automation host and the SNMP/trap receiver) mirrors the way every service and automation article on the site was built.

Build a layer at a time, and verify each before adding the next. Trying to build a whole Super Lab and then debug it is exactly the trap the CCIE lab sets. The layered discipline - campus, then core, then edge, then WAN, then services - is the skill the labs teach.

How to use the library

Read the matching articles in the study hub first, then build the Super Lab from the task list, then verify against the checklist. For the Ticket Gauntlet, do it cold - find each fault from show output before you look at the answer key. Repeat the gauntlet with the faults in a different order until the isolation method is automatic. When you can build the Enterprise Core clean and clear the Gauntlet in the target time, you are ready for the CCIE EI lab.

The CCIE EI v1.1 Field Reference (PDF)

Download the field reference. A one-page condensed reference - administrative distances, the BGP best-path order, OSPF path preference, the transport and SD-WAN quick-refs, and the gotchas that cost hours - every value verified in Cisco Modeling Labs. Download the CCIE EI v1.1 Field Reference (PDF)
