Cisco ASA VPN Group Policies and Tunnel Groups

Two of the most overloaded terms in Cisco ASA VPN configuration are group-policy and tunnel-group. They sound similar, they are configured in the same area, and they both apply attributes to a connecting client. The difference between them is genuinely important: tunnel-groups are the named connection profiles users select; group-policies are the bundle of attributes the gateway pushes to the client once it picks a connection profile. This article breaks both apart, walks the inheritance chain that drives final attribute resolution, and shows real running-config from a live ASAv 9.23(1) in the PingLabz ASA reference lab.

If you have already worked through Cisco ASA AnyConnect SSL VPN Configuration, much of the configuration appearing below will look familiar. Here we treat the two objects as the unit of study, not the side-effect of a connection setup.

Tunnel-Group vs Group-Policy in One Table

One way to keep them straight: tunnel-group is the door (which entrance the client uses), group-policy is the room (what the client finds once inside).

Tunnel-Group Types

Three types exist, and you must specify the type at creation:

From our lab, show running-config tunnel-group shows all three patterns:

ASA-PERIM# show running-config tunnel-group
tunnel-group SSL_PROFILE type remote-access
tunnel-group SSL_PROFILE general-attributes
 address-pool VPN-POOL
 authentication-server-group RADIUS-VPN LOCAL
 authorization-server-group LDAP-VPN
 accounting-server-group RADIUS-VPN
 default-group-policy ANYCONNECT-SSL-GP
tunnel-group SSL_PROFILE webvpn-attributes
 group-alias EMPLOYEES enable
 group-url https://203.0.113.2/employees enable
tunnel-group IKEV2_PROFILE type remote-access
tunnel-group IKEV2_PROFILE general-attributes
 address-pool VPN-POOL
 default-group-policy ANYCONNECT-IKEV2-GP
tunnel-group IKEV2_PROFILE ipsec-attributes
 ikev2 remote-authentication eap query-identity
 ikev2 local-authentication certificate PINGLABZ-SELFSIGNED
tunnel-group 203.0.113.6 type ipsec-l2l
tunnel-group 203.0.113.6 ipsec-attributes
 ikev2 remote-authentication pre-shared-key *****
 ikev2 local-authentication pre-shared-key *****

Three tunnel-groups, three patterns. SSL_PROFILE and IKEV2_PROFILE are remote-access tunnel-groups for AnyConnect SSL and IKEv2 respectively. 203.0.113.6 is a site-to-site tunnel-group whose name is the literal IP of the peer ASA.

The Three Attribute Blocks

A tunnel-group can have up to three sub-blocks of attributes. Which ones apply depends on the tunnel-group type.

The split-by-purpose layout means you do not see ipsec-attributes on a webvpn (clientless) tunnel-group, and you do not see webvpn-attributes on a site-to-site tunnel-group. The CLI hides what does not apply.

The Default Tunnel-Groups

The ASA ships with two default tunnel-groups that you cannot delete:

You can edit these (set their default-group-policy, set a PSK on DefaultL2LGroup) but you cannot remove them. Most production deployments leave them with no AAA configured so that anonymous catch-all logins fail by default.

Group-Policy Anatomy

A group-policy is a bag of attributes pushed to the client. Some are universal (DNS, idle timeout); some are protocol-specific (the SSL DTLS settings only apply to SSL clients).

From our lab:

ASA-PERIM# show running-config group-policy
group-policy DfltGrpPolicy attributes
 dns-server value 10.10.0.10
 default-domain value pinglabz.lab
group-policy ANYCONNECT-SSL-GP internal
group-policy ANYCONNECT-SSL-GP attributes
 dns-server value 10.10.0.10
 vpn-tunnel-protocol ssl-client
 split-tunnel-policy tunnelspecified
 split-tunnel-network-list value SPLIT-TUNNEL
 default-domain value pinglabz.lab
 webvpn
  anyconnect ssl dtls enable
  anyconnect keep-installer installed
  anyconnect ssl rekey time 60
  anyconnect ssl rekey method new-tunnel
  anyconnect dpd-interval client 30
  anyconnect dpd-interval gateway 30
group-policy ANYCONNECT-IKEV2-GP internal
group-policy ANYCONNECT-IKEV2-GP attributes
 dns-server value 10.10.0.10
 vpn-tunnel-protocol ikev2
 split-tunnel-policy tunnelspecified
 split-tunnel-network-list value SPLIT-TUNNEL
 default-domain value pinglabz.lab

Three group-policies are visible:

• DfltGrpPolicy: the system default. It exists whether you configure it or not. You can set its attributes (and we did, with dns-server + default-domain) but the policy itself cannot be deleted.
• ANYCONNECT-SSL-GP: a custom group-policy bound to the SSL_PROFILE tunnel-group. It permits only ssl-client transport, sets a split-tunnel ACL, and configures SSL-specific attributes inside the webvpn sub-block.
• ANYCONNECT-IKEV2-GP: a custom group-policy bound to the IKEV2_PROFILE tunnel-group. Same DNS / domain / split-tunnel ACL but with vpn-tunnel-protocol ikev2 and no webvpn sub-block (because SSL-specific attributes do not apply to an IKEv2 client).

Internal vs External Group-Policies

Notice the internal keyword in group-policy ANYCONNECT-SSL-GP internal. ASA group-policies have two storage types:

• Internal: defined locally on the ASA. The attributes are stored in the ASA config. This is the common case.
• External: the attributes are pulled from an external AAA server (LDAP or RADIUS) on a per-user basis at login. The local config only declares the policy name and the AAA server group to consult.

External group-policies are useful when you want to centralize VPN attributes in your directory. The trade-off is that every connection involves a directory lookup, and you have to map LDAP / RADIUS attributes to ASA attribute names (the ldap attribute-map mechanism). Most deployments keep group-policies internal and use AAA only for authentication and authorization.

The Inheritance Chain (Where Attributes Actually Come From)

For any single connecting user, attributes are resolved in this order, with later sources overriding earlier ones:

1. DfltGrpPolicy: the floor. Every user gets these attributes unless something else overrides them.
2. Tunnel-group's default-group-policy: overrides DfltGrpPolicy for any user landing in this tunnel-group.
3. User-specific group-policy from AAA: if the AAA server (RADIUS or LDAP) returns a Group-Policy attribute, that policy's attributes override the tunnel-group default for this specific user.
4. User attributes from AAA: per-user attributes (banner, framed-IP-address, ACL filter) returned by the AAA server override anything in the group-policies.
5. Dynamic Access Policy (DAP): applied last. DAP records can override anything from steps 1-4 based on a wide set of selectors (AAA attributes + endpoint posture + connection attributes). Full detail in Cisco ASA Dynamic Access Policies (DAP).

The implication: if a user reports a different DNS server than what is configured in their group-policy, check whether AAA is pushing back an override or whether a DAP record is firing. Both happen silently and only show in show vpn-sessiondb anyconnect detail after the fact.

AAA Server Groups on the Tunnel-Group

The tunnel-group's general-attributes sub-block specifies which AAA server group performs each function:

tunnel-group SSL_PROFILE general-attributes
 authentication-server-group RADIUS-VPN LOCAL
 authorization-server-group LDAP-VPN
 accounting-server-group RADIUS-VPN
 default-group-policy ANYCONNECT-SSL-GP

Three independent functions, often pointing at different server groups:

• Authentication: who is the user? RADIUS verifies the password. The trailing LOCAL says fall back to the local username database if RADIUS is unreachable.
• Authorization: what can this user do? LDAP returns group memberships and per-user attributes that map to the ASA's group-policy attributes.
• Accounting: log the session. RADIUS receives Accounting-Start when the user connects and Accounting-Stop when they disconnect, with byte counts and session duration.

The full AAA configuration for each protocol is in Cisco ASA AAA for VPN: LDAP, RADIUS, and TACACS+.

Site-to-Site Tunnel-Groups Are Different

For site-to-site IPsec, the tunnel-group name is the peer's IP address (or hostname). When a peer initiates and presents that source IP, the ASA looks up a tunnel-group of that name to find the PSK or trustpoint to use.

tunnel-group 203.0.113.6 type ipsec-l2l
tunnel-group 203.0.113.6 ipsec-attributes
 ikev2 remote-authentication pre-shared-key *****
 ikev2 local-authentication pre-shared-key *****

The PSK is hidden in the show output. The tunnel-group has no general-attributes block configured because L2L tunnels do not need an IP pool, AAA, or a default group-policy; the policy attributes are baked into the crypto map and the IPsec proposal.

Key Takeaways

The tunnel-group is the named connection profile (the door). The group-policy is the bag of attributes pushed to the client (the room). They are linked by the tunnel-group's default-group-policy attribute. Most deployments have one tunnel-group per transport (SSL, IKEv2, L2L) with a matching group-policy, plus a per-OU tunnel-group for distinct authorization profiles.

The attribute-resolution chain runs DfltGrpPolicy > tunnel-group default > AAA-returned group-policy > AAA per-user attributes > DAP. When attribute behavior is surprising, walk the chain in show vpn-sessiondb anyconnect detail to find which layer is actually pushing the value.

For the full Cisco ASA reference, including site-to-site IPsec, NAT, ACLs, failover, and the troubleshooting tools, see the Cisco ASA pillar. For the AAA wiring that ties tunnel-groups to a directory, see Cisco ASA AAA for VPN: LDAP, RADIUS, and TACACS+; for the runtime override layer, see Cisco ASA Dynamic Access Policies (DAP).
