Cisco ASA Active/Standby Failover Configuration

Active/standby failover on the Cisco ASA is the simplest high-availability mode the platform supports: two physically identical firewalls connected by a dedicated failover link, one unit forwarding traffic, the other watching and waiting. When the active unit dies, the standby promotes itself in under a second and inherits every IP and MAC address of the formerly-active. To users, traffic flows continue with at most a single dropped packet. This article walks through the full configuration, the show commands you read to verify it, and the few gotchas that bite on real builds. Every config block below was tested as part of building the PingLabz ASA reference lab; lab-specific constraints are noted at the end.

If you are pairing this with stateful sync (so existing TCP sessions also survive failover), the next article in the cluster is stateful failover and interface tracking. If you are diagnosing a failover problem - both units active, neither active, slow promotion - skip ahead to common outage scenarios for the split-brain section.

What Active/Standby Failover Actually Does

Two ASAs share a failover link (a directly-connected layer-2 link, dedicated to failover communication) and a failover key (a shared secret authenticating the protocol). Both units boot, the primary becomes Active, the secondary becomes Standby Ready. The active unit owns every configured IP - the standby's data interfaces have a separate "standby" IP that nothing actually uses for traffic. Failover hellos go over the failover link; the standby unit also monitors layer-2 interface state.

When the active unit fails - power loss, kernel panic, monitored-interface down, or no failover hello received within the holdtime - the standby:

1. Detects the failure (within ~3 seconds at default polltimes, sub-second with aggressive tuning).
2. Promotes itself to Active.
3. Sends gratuitous ARP for every owned IP, telling all neighboring devices that the new MAC owns the address.
4. Begins forwarding traffic.

What does NOT survive vanilla active/standby (without stateful sync): existing TCP and UDP sessions. Each connection has to re-establish through the new active unit. SSH disconnects, HTTP rebuffers, VPN tunnels reauthenticate. Add stateful failover (the topic of the next article) to preserve sessions, but the base failover mechanism does not.

Prerequisites

The standby-IP requirement bites the most. A /30 outside subnet has no spare address for a standby IP. If your perimeter has /30 transits everywhere, plan a re-IP to /29 before you commit to failover.

Topology and Addressing

The pair we are building:

             INSIDE-RTR
                  |
              10.10.0.0/24
                  |
        +---------+---------+
        |                   |
   ASA-PERIM           ASA-PERIM-SEC
   (Primary)            (Secondary)
   inside .254          inside .253 (standby)
   outside .2           outside .3 (standby)
   dmz     .1           dmz     .2 (standby)
        |                   |
        +-----FAIL-LINK-----+
        G0/3               G0/3
        169.254.99.1/30    169.254.99.2/30
        |                   |
              outside G0/1
              203.0.113.0/29
                  |
              ISP-RTR
                  |
              dmz   G0/2
              192.168.50.0/24
                  |
              dmz-host

The failover link uses a link-local /30 (169.254.99.0/30) because nothing else on the network needs to route to it. Pick any private /30 you like; the addresses never leave the link.

Primary Unit Configuration

On the unit you want to be primary:

! 1. The failover link physical interface, no nameif, no IP - reserved for failover.
interface GigabitEthernet0/3
 description LAN/STATE Failover Interface
 no shutdown
 no nameif
 no security-level
 no ip address

! 2. Standby IPs on every data interface (must be in the active interface's subnet)
interface GigabitEthernet0/0
 nameif inside
 security-level 100
 ip address 10.10.0.254 255.255.255.0 standby 10.10.0.253
!
interface GigabitEthernet0/1
 nameif outside
 security-level 0
 ip address 203.0.113.2 255.255.255.248 standby 203.0.113.3
!
interface GigabitEthernet0/2
 nameif dmz
 security-level 50
 ip address 192.168.50.1 255.255.255.0 standby 192.168.50.2

! 3. Failover identity, key, and link configuration
failover lan unit primary
failover lan interface FAIL-LINK GigabitEthernet0/3
failover key STRONG_FAILOVER_KEY
failover replication http

! 4. Failover IP on the failover link (active and standby IP, both on the link)
failover interface ip FAIL-LINK 169.254.99.1 255.255.255.252 standby 169.254.99.2

! 5. Polltimes (defaults shown - tighten for production)
failover polltime unit 1 holdtime 15
failover polltime interface 5 holdtime 25

! 6. Optional: which interfaces to monitor for failover triggering
monitor-interface inside
monitor-interface outside
monitor-interface dmz

! 7. Bring it online
failover

The order matters. Configure the failover link interface (block 1), the data interface standby IPs (block 2), the failover identity and link details (block 3-4), polltimes (block 5), and only then enable failover (failover). Enabling before the link is up triggers the unit into "Active waiting for peer" with no peer to find.

Secondary Unit Configuration

The secondary needs only a minimal bootstrap. Once failover establishes, the primary REPLICATES its full configuration to the secondary, overwriting whatever was there.

! Hostname (just for visibility - replication does NOT change hostname)
hostname ASA-PERIM-SEC
enable password Cisco1@3

! Failover link interface (must match primary)
interface GigabitEthernet0/3
 no shutdown
 no nameif
 no security-level
 no ip address

! Failover identity, key, link interface, link IP - must match primary
failover lan unit secondary
failover lan interface FAIL-LINK GigabitEthernet0/3
failover key STRONG_FAILOVER_KEY
failover interface ip FAIL-LINK 169.254.99.1 255.255.255.252 standby 169.254.99.2

! Bring it online
failover

That is the full secondary bootstrap. Once failover is enabled, the unit listens on the failover link, hears the primary's hello, authenticates the key, identifies as the secondary, and pulls the primary's config across.

Verifying with show failover

The single most useful command on a failover pair:

ASA-PERIM# show failover
Failover On
Failover unit Primary
Failover LAN Interface: FAIL-LINK GigabitEthernet0/3 (up)
Reconnect timeout 0:00:00
Unit Poll frequency 1 seconds, holdtime 15 seconds
Interface Poll frequency 5 seconds, holdtime 25 seconds
Interface Policy 1
Monitored Interfaces 3 of 1290 maximum
MAC Address Move Notification Interval not set
failover replication http
Version: Ours 9.23(1), Mate 9.23(1)
Serial Number: Ours 9AGRS9XXXX, Mate 9AGRS9YYYY
Last Failover at: 14:23:10 UTC May 10 2026
        This host: Primary - Active
                Active time: 1234 (sec)
                slot 0: ASAv hw/sw rev (/9.23(1)) status (Up Sys)
                  Interface inside (10.10.0.254): Normal (Monitored)
                  Interface outside (203.0.113.2): Normal (Monitored)
                  Interface dmz (192.168.50.1): Normal (Monitored)
        Other host: Secondary - Standby Ready
                Active time: 0 (sec)
                slot 0: ASAv hw/sw rev (/9.23(1)) status (Up Sys)
                  Interface inside (10.10.0.253): Normal (Monitored)
                  Interface outside (203.0.113.3): Normal (Monitored)
                  Interface dmz (192.168.50.2): Normal (Monitored)

Read top to bottom. Failover On is the must-be-line. Failover LAN Interface: ... (up) means the failover link is alive. The Version and Serial Number lines confirm both units are on the same software and identify each. The This host: Primary - Active and Other host: Secondary - Standby Ready are the success state. Each interface should show Normal (Monitored); anything else (Failed, No Link, Testing) is a problem on that interface.

show failover state for the One-Liner

ASA-PERIM# show failover state
                This host -   Primary
                              Active           None
                Other host -  Secondary
                              Standby Ready    None

====Configuration State===
        Sync Done
====Communication State===
        Mac set

Three things to like: This host Active, Other host Standby Ready, Configuration State Sync Done. If Sync Done is missing or shows Sync Failed, the secondary's startup config diverged from what the primary tried to push - typically a license or interface mismatch.

show failover history: The Transition Log

ASA-PERIM# show failover history
==========================================================================
From State                 To State                   Reason
==========================================================================
14:22:55 UTC May 10 2026
Negotiation                Just Active                Other unit is not active
14:22:55 UTC May 10 2026
Just Active                Active Drain               Other unit is not active
14:22:55 UTC May 10 2026
Active Drain               Active Applying Config     Active unit
14:22:55 UTC May 10 2026
Active Applying Config     Active Config Applied      Active unit
14:22:55 UTC May 10 2026
Active Config Applied      Active                     Active unit
==========================================================================

This is the postmortem record. Every state transition the unit went through, with timestamps and reasons. After a failover event, this is the first thing to read - it tells you the moment of failure and why the unit promoted (Comm Failure, Interface Down, Power Loss, etc.).

Testing the Failover

Before you trust failover for the first time, exercise it deliberately. Two test scenarios:

1. Manual switchover. On the active unit: no failover active. The unit transitions to Standby, the peer transitions to Active. Run a continuous ping from a client; you should see at most a single dropped packet. After the test, no failover active on the (formerly-)standby to fail back. Document the behavior in your maintenance runbook.
2. Failover-link disconnect. Pull the failover cable. The active stays Active. The standby goes to "Failed" (because it sees no hellos). Reconnect; both units should resync within polltime. Do not simulate this by disabling the failover-link interface via CLI - that triggers a different code path. The cable pull is the realistic test.

Avoid the third "tempting" test: powering off the active unit. It works, but it leaves the standby Active and the formerly-active in a state where it might come back as Active too if the failover link is slow to converge. Always do power-off testing in a maintenance window with two operators on console.

Polltime Tuning

Default polltimes give a worst-case failover detection of 15 seconds (1-second poll, 15-second hold). For most environments, that is fine. For latency-sensitive workloads, tighten:

failover polltime unit msec 200 holdtime msec 800
failover polltime interface msec 500 holdtime 5

200 ms unit poll with 800 ms hold gives sub-second failover detection. Below 200 ms is supported but increases CPU load on both units; only do it if you know you need it. Interface polltime should remain at 500 ms or higher - lower values cause spurious interface flaps.

Lab Constraints (and Production Equivalents)

Two constraints surfaced in the PingLabz ASA reference lab that are worth flagging:

• ASAv refuses Management0/0 as the failover LAN interface. The ASA virtual platform explicitly disallows the management interface for the failover LAN role with the error Management interface cannot be configured as failover on this platform. Use a regular GigabitEthernet, as shown in the configs above. On physical ASA models this restriction does not apply.
• /30 outside subnets do not have room for a standby IP. A /30 has only 4 addresses (network, broadcast, ISP next-hop, ASA active). Failover requires a standby IP on the same subnet. Re-IP to /29 - which gives you 6 usable addresses - or migrate to a /28 if the upstream allows. The configs above assume /29 on outside (203.0.113.0/29).

Key Takeaways

Active/standby failover is straightforward: identical hardware, dedicated failover link, matching failover key, standby IP on every monitored data interface. The primary boots to Active and the secondary boots to Standby Ready; show failover is the single command that tells you whether the pair is healthy. Add stateful failover from the next article to also preserve TCP sessions across the failover. And for the failure modes - both units active, neither active, slow promotion - common outage scenarios walks the diagnostic for each. The full Cisco ASA reference cluster has the rest of the perimeter playbook.
